MG17416 - Square D - Molded Case
Overview
Product Specifications - MG17416 - Square D Molded Case Circuit Breakers
-
Part Number:
MG17416 -
Manufacturer:
-
Family:
Multi9 -
Pole:
1 -
Amp:
15 -
Volt:
240 -
Phase:
1
-
Category:
-
Connection:
Bolt-On -
Type:
MG -
Functions:
NGC -
Protection:
Thermal Magnetic -
AIC Ratings:
10kA@240V
Dimensions
-
Dimensions (HxWxD):
3.19 x 0.71 x 2.87 -
Weight:
0.24 lbs
Standards
Product Description - MG17416 - Square D Molded Case Circuit Breakers
Introducing the MG17416 from Schneider Electric's Multi9 series, also known as Square D. This miniature circuit breaker, identified as type MG, is designed for single-phase applications. It offers a 15A capacity at 120/240V with a standard interrupting capacity of 10kA at 240V. Featuring a Bolt-On design and C curve characteristics, it provides reliable protection. UL listed and CSA certified, it is suitable for reverse feed and serves as a supplementary protector in electrical systems
