MGN61332 - Square D - Molded Case

Product image 1

MGN61332 - Square D - Molded Case

Overview

Product Specifications - MGN61332 - Square D Molded Case Circuit Breakers

  • Category:

    Molded Case Breakers / 3-Pole

  • Connection:

    Feed-Thru

  • Type:

    C60

  • Functions:

    NGC

  • Protection:

    Thermal Magnetic

  • AIC Ratings:

    10kA@480V

Dimensions

  • Dimensions (HxWxD):

    5.55 x 2.13 x 2.70

  • Weight:

    0.73 lbs

Standards

CSA Approved logo

Product Description - MGN61332 - Square D Molded Case Circuit Breakers

Introducing the MGN61332 from Schneider Electric's Multi9 series, also known as Square D. This miniature molded case circuit breaker, classified as type C60, is designed for three-phase applications. It is UL listed and CSA certified, offering a 20A capacity at 480V with a standard interrupting capacity of 10kA at 480V. Featuring a Feed-Thru design and C Curve characteristics, it offers reliable protection. With Long-Time (LI) and Instantaneous trip functions, as well as line and load side lug terminals, it ensures versatile installation options. Equipped with single-barrel wire lugs, it is suitable for reverse feeding in electrical systems

Select Condition
From $24.60

Original: $81.99

-70%
MGN61332 - Square D - Molded Case—

$81.99

$24.60
