QOB350GFI - Square D - 50 Amp GFCI Breaker

QOB350GFI - Square D Bolt-On 50 Amp GFCI Breaker

Specifications:

• Product: Miniature circuit-breaker
• Range: QO
• Current Rating: 50 A
• Voltage Rating: 208Y/120 V AC
• Mounting Type: Bolt-on
• Number of Poles: 3P
• Circuit Breaker Type: Ground fault protecting class A 6 mA
• Ratings: Not rated
• Electrical Connection: Box lugs
• Inturrupt Rating: 10 kA 208Y/120 V AC 50/60 Hz
• Number of Panel Spaces: 3
• Wire Size: AWG 12...AWG 4 aluminium, AWG 14...AWG 6 copper
• Tightening torque: 40.71 lbf.in (4.6 N.m) 0.00...0.02 in² (2.5...10 mm²) AWG 16...AWG 14), 40.71 lbf.in (4.6 N.m) 0.01...0.03 in² (4...20 mm²) AWG 12...AWG 4)
• Certifications: UL listed, CSA

• Ambient Rating: 104 Degree F (40 Degree C)
• Authentic Square D Product
• Dimensions (H x W x L): 4.12" x 2.25" x 2.91"
• 3 phase

Alt model: q0b350gfi
