PKA36080U31A - Square D - Molded Case Circuit Breaker

Product image 1

PKA36080U31A - Square D - Molded Case Circuit Breaker

Overview

Product Specifications - PKA36080U31A - Square D Powerpact Circuit Breaker

  • Category:

    Molded Case / 3-Pole

  • Connection:

    I-Line Style Plug-In

  • Type:

    PKA

  • Functions:

    LI - Long-Time and Instantaneous

  • Protection:

    Solid State

  • AIC Ratings:

    50kA@600V | 50kA@480V | 65kA@240V

Dimensions

  • Dimensions (HxWxD):

    12.86" x 8.05" x 8.27"

  • Weight:

    8.05 lbs

Standards

CSA Approved logo

Additional Details

  • Terminal:

    AL800M23K

  • Module Type:

    P-Frame

  • Trip Unit Technology:

    Electronic, standard, MicroLogic 3.0, LI

  • Line Rated Current:

    800 Amp

  • [Ue] rated operational voltage:

    600 V AC 50/60 Hz UL 489

  • Mounting Mode:

    I-Line bracket

  • Breaking Capacity Code

    K

  • Electrical Connection:

    I-Line connection line / Lugs load

  • Suitability for isolation:

    Yes IEC 60947-2

  • Continuous Current Rating

    80%

  • Control Type:

    Toggle

  • AWG Gauge:

    AWG 3/0...500 kcmil Aluminum/Copper Terminals

Product Description - PKA36080U31A - Square D Powerpact Circuit Breaker

This Square D circuit breaker is perfect for high-performance applications. It offers 800A rated current, 600VAC rated operational current, and a 50kA@600VAC breaking capacity for reliable protection against electrical surges. The 3-pole I-Line breaker has an 80% continuous current rating and features Micrologic 3.0 electronic trip unit technology. This breaker's dimensions are 12.86" (H) x 8.05" (W) x 8.27" (D).

Select Condition
From $3,598.80

Original: $11,995.99

-70%
PKA36080U31A - Square D - Molded Case Circuit Breaker—

$11,995.99

$3,598.80
