CAD50BD - Square D - Motor Control Part And Accessory
Overview
Product Specifications - CAD50BD - Square D Motor Control Part And Accessory
-
Part Number:
CAD50BD -
Manufacturer:
-
Family:
TeSys D
-
Category:
-
Type:
CAD
Dimensions
-
Dimensions (HxWxD):
3.03 x 1.77 x .3.66 -
Weight:
1.28 lbs
Standards
Product Description - CAD50BD - Square D Motor Control Part And Accessory
TeSys D control relay, 5 contacts (5NO), 10A/690V, for control of electromagnetic loads AC-15/DC-13. It provides a 24V DC control circuit with no inrush consumption and equipped with a surge suppression device, connection by screw clamp terminals. For high operating rates until 180 cycles/min and ambient temperature -40/+60°C, it procures high reliability and durability. Compact (45mm width), for clipping on 35mm DIN rail or fixing by screw. Multi standards certified (IEC, UL, CSA, CCC, EAC, Marine), Green Premium product (RoHS/REACh).
Original: $87.99
-70%$87.99
$26.40Product Information
Product Information
Shipping & Returns
Shipping & Returns
Description
Overview
Product Specifications - CAD50BD - Square D Motor Control Part And Accessory
-
Part Number:
CAD50BD -
Manufacturer:
-
Family:
TeSys D
-
Category:
-
Type:
CAD
Dimensions
-
Dimensions (HxWxD):
3.03 x 1.77 x .3.66 -
Weight:
1.28 lbs
Standards
Product Description - CAD50BD - Square D Motor Control Part And Accessory
TeSys D control relay, 5 contacts (5NO), 10A/690V, for control of electromagnetic loads AC-15/DC-13. It provides a 24V DC control circuit with no inrush consumption and equipped with a surge suppression device, connection by screw clamp terminals. For high operating rates until 180 cycles/min and ambient temperature -40/+60°C, it procures high reliability and durability. Compact (45mm width), for clipping on 35mm DIN rail or fixing by screw. Multi standards certified (IEC, UL, CSA, CCC, EAC, Marine), Green Premium product (RoHS/REACh).
